3 V, SILICON MMIC
FREQUENCY CONVERTER   (3 V, SILICON MMIC频率转换器UPC2758T)

FEATURES:

• WIDE BAND OPERATION UP TO 2.5 GHz
• LOW VOLTAGE OPERATION: 2.7 V Minimum
• LOW POWER CONSUMPTION: 15 mW (UPC2757T)
• POWER SAVE FUNCTION
• SUPER SMALL PACKAGE
• TAPE AND REEL PACKAGING OPTION AVAILABLE

DESCRIPTION:

The UPC2757T and UPC2758T are L-Band Frequency Con-
verters manufactured using the NESAT III MMIC process.
These products consist of a double balanced mixer, IF ampli-
fier and LO buffer amplifier. The UPC2757T is designed for
low power consumption while the UPC2758T is designed for
low distortion. Both devices operate on a  3 volt supply voltage
making them ideal for portable hand held cellular, GPS, PCN
and wireless LAN applications.
NEC's stringent quality assurance and test procedures en-
sure the highest reliability and performance.

脚定义：
